| № | Parameters | Values |
|---|---|---|
| 1 | Productivity, m3/ч | не более 350 |
| 2 | Maximum size of the material, mm, no more | 40 |
| 3 | Air suction, %, no more | 1 |
| 4 | Electric motor: | |
| - Type | AIMR180 S4 | |
| - Shaft rotation speed, rpm | 1500 | |
| - Rated power, kW | 22 | |
| 5 | Reducer: | |
| - Type | 1C2U-315N | |
| - Gear ratio | 40 | |
| - Execution | 21 | |
| 6 | Adjusted sound power level dB, no more | 108 |
| 7 | Overall dimensions of the feeder without drive, mm: | |
| - length | 1895 | |
| - width | 1525 | |
| - height | 1220 | |
| 8 | Overall dimensions of the feeder assembly, mm: | |
| - length | 3550 | |
| - width | 1575 | |
| - height | 1560 | |
| 9 | Drum diameter, mm | 900 |
| 10 | Weight, t | ~5 |
| Technical specifications | |
|---|---|
| ZHBA-0.9-M (SBP2- 350A) |
|
| Power supply capacity, t/h | 350 |
| Air suction when working under load, % | 1,0 |
| Rated engine power, kW | 22 |
| length | 3100 |
| width | 1800 |
| height | 1700 |
| Масса, кг | 4000 |
| Technical specifications | |
|---|---|
| Capacity, m³/h | 350 |
| Maximum dimensions of the pieces, mm | 40 |
| Air suction when working under load, % | 1 |
| Overall dimensions, mm: | |
| length | 1510 |
| width | 1393 |
| height (without funnel) | 1560 |
| height (with funnel) | 1395 |
| Weight, without drive, kg | 2922 |
